The Silhouette Cameo 4 is a DIY cutting machine that helps cut various materials, including cardstock, felt, balsa wood, leather, etc. This machine is loaded with technological improvements from its previous models. It includes Silhouette Studio software that helps in designing your crafts. If you are a beginner and want to learn to use Silhouette Cameo 4, we will help you with this. Let’s learn how to use a Silhouette Cameo 4.
Silhouette Cameo 4 Features
There are many useful features the Silhouette Cameo carries. Some features are more useful than others and will help you throughout the crafting.
Bluetooth Connectivity
Your Silhouette Cameo 4 is Bluetooth enabled and offers a wireless connection option. Otherwise, you can use a USB adapter with it.
Cut Speed
The Silhouette Cameo 4 has a remarkable speed. It can cut at a speed of 30 cm per second, which is the fastest speed in the industry. Plus, it can exert a pressure of 5000 grams.
Print And Cut
The Cameo 4 provides a great print and cut feature, which is good for making stickers, labels, charts, etc. It allows you to create designs and print them with registration marks that can be easily ready by Silhouette Cameo 4.
Matless Cutting
Cutting mats are extremely useful in cutting materials, but the Cameo 4 allows matless cutting with various materials.
Automatic Tool Detection
You don’t need to worry about selecting the wrong tool or forgetting to change the tool in the design program. The Cameo 4 detects the tool automatically that you are using.
Two Tool Carriages
The Silhouette Cameo 4 comes with two tool carriages that can detect the blades you are using automatically. These carriages are different from the carriages of previous machines. Hence, if you need to use old tools, you should use a carriage adapter.
Adjustable Rollers
The Cameo 4 is equipped with white rollers that can expand the size you are working on, such as A4, Letter, 12 inches, and 13 inches.
How To Install Silhouette Studio?
The Silhouette Studio is software from Silhouette that you can use to customize your designs and make personalized crafts. You can get the Silhouette Studio software from the Silhouette America website. It mainly has three versions you can upgrade to later if needed. One good thing about Silhouette is that it’s not web based. Hence, you can download and install it on your system even if the internet connection isn’t available.
What Can Your Silhouette Cameo 4 Cut?
The Cameo 4 can cut materials up to 12 inches wide using a cutting mat. However, with some other materials, it can cut up to 10 feet long. Plus, it has a clearance of 2mm that can cut thick materials as well. These are some of the materials you can cut with the Silhouette Cameo 4. Also, different materials need different blades.
- Adhesive vinyl
- Paper
- Heat transfer vinyl
- Cardstock
- Vellum
- Canvas
- Fabric
- Cardboard
- Felt
- Balsa wood
- Craft foam
How To Use A Silhouette Cameo 4?
This machine can cut materials up to 12″ in width, and its pro version can cut materials up to 24″ in width. Also, the Cameo 4 has Bluetooth connectivity. Hence, you can connect it wirelessly to your system. This feature is useful when your machine and system are apart from each other. You can also connect them via a USB cord.
To use your Cameo 4, you need to place your material on the cutting mat aligned with the grid. Then, insert the cutting mat into the Silhouette Cameo machine by pushing it under the white rollers. After that, press the load button, an arrow-like button on the right side of the machine. Then, the machine will pull up the cutting mat.
Now, on the Silhouette software, set up your files and make sure that lines are ready to cut. Then, select the material from the dropdown menu. During this, the blade settings will be updated automatically. The Silhouette Cameo 4 also uses an auto blade which means you only need to insert the auto blade in the left-hand carriage, and then it will adjust the blade depth depending on the settings from the dropdown menu.
When you take a test cut, the Silhouette machine will cut a small triangle in the upper left corner of the material. When the design is ready to cut, press sends at the bottom, and the cutting will start. Always remember to take a test cut by clicking the test button.
Then, you need to check the depth of this cut. If the depth is not as expected, go to the Silhouette Studio and adjust the blade settings manually. When your design has cut properly, press the unload button on the machine to unload your mat.
