SVR Global is the top Concentric butterfly valve manufacturer in USA. In New Mexico, North Carolina, and New Jersey, we are the leading provider of valves to the water and wastewater, marine, and chemical sectors. Industries frequently employ concentric butterfly valves to control the flow of liquids, gases, or slurries. Because the disc's centerline and the valve body's centerline are in line, it is known as a "concentric" valve. This kind of valve is frequently utilised in situations where tight shutdown and low-pressure drop are necessary.
A form of shut-off valve with a small and straightforward design is the concentrated butterfly valve. It is a widely used butterfly valve configuration. These valves have elastomer body lines built into them, allowing for tight, secure sealing as well as assurance that the body material won't react with the media, preventing corrosion from the impact of the fluid. They are quite simple to install, whether you need to mount them vertically or horizontally.
INDUSTRIES
· Chemical Industry
· Oil & Gas Industry
· Petrochemical Industry
· Energy Industry
· LNG & LPG Industry
· Marine Industry
· Mining industry
· Textile industry
APPLICATION
• Water treatment: Concentric butterfly valves are used in water treatment facilities to regulate the water flow through pipelines, tanks, and reservoirs.
• Chemical processing: Concentric butterfly valves are employed in the chemical industry to control the flow of corrosive, abrasive, or viscous fluids.
• Oil and gas: In the oil and gas sector, concentric butterfly valves are used to control the flow of fluids in pipelines, refineries, and offshore platforms, including oil, gas, and other substances.
• Power generation: Concentric butterfly valves are used in power production plants to control the flow of steam or water in turbines, boilers, and heat exchangers.
Concentric butterfly valves are used in the mining sector to control the flow of slurry, water, or chemicals in pipelines and processing facilities.
ADVANTAGES
Concentric butterfly valves feature a straightforward and lightweight design that makes them simple to install and maintain. They are appropriate for situations with limited space due to their small footprint.
• Low pressure drop: Concentric butterfly valves feature streamlined disc designs that minimise pressure drop across the valve, reducing energy use and enhancing system effectiveness.
Concentric butterfly valves are appropriate for applications that call for rapid flow control because of their simple and fast-acting design, which enables short opening and shutting periods.
• Tight shutdown: Concentric butterfly valves offer a tight shutoff when fully closed, assisting in the prevention of leaks and ensuring the safety of the process.
· Cost-effectiveness: Concentric butterfly valves, particularly those in bigger sizes, are typically less expensive than other valve designs.
• Simple design makes it simple to maintain and repair concentrative butterfly valves, minimising downtime and maintenance expenses.
SVR Global, the Concentric butterfly valve manufacturer in USA provides valves with the following specifications:
Body Material: cast carbon steel (WCC, WCB, WC6), stainless steel [SS316, SS304, SS316L, SS904L, CF8, CF8M, F31L, F91], duplex steel and super duplex steel (F51, F53, F55), cast iron, ductile Iron.
Size: 2” – 48”
Class: 150 to 300; PN 6 – PN 25
Ends: wafer, flanged, lug
Operations: lever operated, gear operated, pneumatic actuated and electric actuated.
Visit our website for more information- https://svrglobal.net/products/concentric-butterfly-valve/
