Titanium is the ninth most abundant element in the earth's crust and the fourth most commonly used structural metal. In nature, it occurs only as a mineral (ore) in combination with oxygen or iron (rutile, TiO2, or ilmenite, FeTiO3).
Titanium is a lightweight material whose density is approximately 60 percent of steel's and 50 percent of nickel and copper alloys'. It was recognized in the 1950s as a desirable material for aerospace applications—especially airframe and engine components. In the 1960s and 1970s, titanium was considered for use in vessels and heat exchangers in corrosive chemical process environments. Typical applications included marine, refinery, pulp and paper, chlorine and chlorate production, hydrometallurgy, and various other oxidizing and mildly reducing chemical services.
if you are looking for best Stainless Steel 904L read till the end
In the 1980s and 1990s, titanium began to be used for many nontraditional applications, including tubulars for geothermal energy extraction and oil and gas production, consumer goods (such as sporting equipment), food processing, biomedical implants, and automotive components.
According to the U.S. Geological Survey (USGS), 52 million pounds of titanium were produced in the U.S. in 2000; worldwide, more than 100 million pounds were produced.
Processing Titanium Ore
Titanium sponge is obtained by reacting rutile ore with chlorine and coke, followed by magnesium (Kroll) reduction and then vacuum distillation to remove excess magnesium and magnesium chloride. Titanium sponge is pressed into blocks to make a consumable electrode and then melted in an inert environment under vacuum to produce a titanium ingot.
Typically, vacuum-arc remelting (VAR), electron-beam (EB) hearth melting, or plasma-arc melting (PAM) processes are used to melt titanium. From ingot, titanium is processed into various mill products, dependent on alloy, which include bar, bloom, billet, slab, plate, sheet, strip, welded tube and pipe, and seamless pipe.
Properties of Titanium
Titanium is well-known for its unique combination of properties, which include low modulus of elasticity, stable and steadfast oxide film (which provides excellent corrosion and erosion resistance), and a high strength-to-density ratio.
Titanium's fabricability, weldability, and formability make possible its use in many shop and field operations. Although gas tungsten arc welding (GTAW) is the primary joining process, many other procedures are suitable. Titanium's weld characteristics are similar to those of stainless steels' or nickel alloys', with surface cleanliness and inert gas shielding being important. Fabricators often perform seal welding and butt welding operations in the shop and the field.
As for formability, titanium can be bent, cold-formed, and drawn readily. Furthermore, most industrial titanium alloys do not require stress relief annealing after cold forming.
Titanium Tube and Pipe—Types and Uses
Welded titanium tube is available in outside diameters (ODs) from 0.5 to 2.5 inches and wall thicknesses from 0.020 to 0.109 in. Welded pipe is available in standard industry sizes from 0.75 to 8 in. nominal OD with nominal wall thicknesses in Schedules 5, 10, and 40. Seamless pipe with ODs from 2 to 20 in., wall thicknesses from 0.25 to 2.0 in., and lengths to 60 feet also can be made.
Welded titanium tube and pipe can be tested with many of the same techniques used for steel tube and pipe. Eddy current, pneumatic, and ultrasonic testing all are applicable to titanium. Procedures for eddy current and ultrasonic testing can be used to meet or exceed American Society for Testing and Materials (ASTM) B-338 and to help ensure tube reliability.
Welded tubing and pipe are available in several grades
And if you are looking to Stainless Steel 904L
visit the link now - https://titanium.co.id/2016/09/26/special_stainless_steel/
