Sai Steel & Engineering Co. has some restrictions on SA 387 grade 9 class 2 Steel Plate. By maintaining a long-term cooperative relationship with the wants of the SA 387 grade 9 class 2 Steel Plate, we offer an honest, cost-effective and best partnership. Our toll bill is additionally valid in several countries/regions today. like Saudi Arabia , Kuwait, Qatar, Oman, Yemen, United Arab Emirates, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa , South America, Brazil, India, Australia, Egypt. We are very happy together with your inquiry.
We provide SA 387 grade 9 class 2 Steel Plate rigorously tested steel plates at reasonable prices. These SA 387 grade 9 class 2 steel plate are made from the very best quality tough materials available to make sure total quality.
Consistent with customer needs, we will provide SA 387 grade 9 class 2 steel plate that meets the dimensions and thickness of the violin. Taking under consideration the gathering of particularly experienced qualified professionals and using the newest social mechanical changes, Sai Steel & Engineering Co. has provided customers round the world with a tremendous SA 387 grade 9 class 2 steel plate plates and profiles. Additionally, all SA 387 grade 9 class 2 steel plate stocks to chop the plate into the dimensions and shape shown on your work, the nuts and bolts on the table, and every one other parts. this is often our job. Simply and reliably check the guaranteed quality system.
What is sa 387 grade 9 class 2 Steel Plate ?
Our SA 387 grade 9 class 2 steel plate come from high-quality steel manufacturers everywhere the planet. Like all our suppliers, these manufacturers are selected and evaluated at our security conference. SA 387 grade 9 class 2 steel plate -Weldable steel plates for weighing tanks and kettles, wont to contact high temperatures. Positive material conditions include chromium and molybdenum, which undeniably imposes more restrictions on the utilization of steel and thermal certification.
Manufacturers serving the oil, gas, and petrochemical industries use SA387 Class 9.Weldable steel plates for weighing tanks and boilers exposed to high temperatures. the foremost concentrations of chromium and molybdenum that structure the most undisputed steel use thermal barriers and certifications. The manufacturer of the upkeep oil uses SA387 Grade 9. , gas and petrochemical industries.
Equivalents:
BS
EN
ASTM/ASME
DIN
…
…
SA387-9-2
…
SA 387 grade 9 class 2 Steel Plate Grade and Specification
Grades
- ASTM A387 Grade 5 Class 2,Grade 9 Class 2,Grade 11 Class 2,Grade 12 Class 2,Grade 22 Class 2,Grade 91 Class 2.
- ASME SA387 Grade 5 Class 2,Grade 9 Class 2,Grade 11 Class 2, Grade 12 Class 2,Grade 22 Class 2,Grade 91 Class 2.
- EN 10028:16Mo3,13CrMo45,10CrMo910
- BS 1501:620B, 621B,622B
Chromium & Molybdenum content (according to the ASME specification):
Designation
Nominal Chromium Content (%)
Nominal Molybdenum Content (%)
SA387 Grade 9
9.00%
1.00%
SA 387 grade 9 class 2 Steel Plate Properties
Chemical Properties Of sa 387 grade 9 class 2 Steel Plate
Element
Chemical Composition (%)
SA 387 Grade 9
Carbon:
Heat Analysis:
0.15 max
Product Analysis:
0.15 max
Manganese:
Heat Analysis:
0.30 – 0.60
Product Analysis:
0.25 – 0.66
Phosphorus:
Heat Analysis:
0.030
Product Analysis:
0.030
Sulphur (max):
Heat Analysis:
0.030
Product Analysis:
0.030
Silicon:
Heat Analysis:
1.00 max
Product Analysis:
1.05 max
Chromium:
Heat Analysis:
8.00 – 10.00
Product Analysis:
7.90 – 10.10
Molybdenum:
Heat Analysis:
0.90 – 1.10
Product Analysis:
0.85 – 1.15
Vanadium:
Heat Analysis:
0.04 max
Product Analysis:
0.05 max
Mechanical Properties Of sa 387 grade 9 class 2 Steel Plate
Designation:
Requirement:
Grade 9
SA387 Grade 9
Tensile strength, ksi [MPA]
75 to 100 [515 to 690]
Yield strength, min, ksi [MPa]/(0.2% offset)
45 [310]
Elongation in 8 in. [200mm], min %
…
Elongation in 2 in. [50mm], min, %
18
Reduction of area, min %
45 (measured on round test specimens)40 (measured on flat test specimen)
Chrome Moly Steel Plate Stock
- SA 387 Chrome Moly Steel
- BS 1501 Chrome Moly Steel
- EN-10028-2 Chrome Moly Steel
Normal Application of sa 387 audit 9 class 2 Steel Plate
- boilers and pressure vessels,
- Warmth exchangers
- Ribs, fittings and valves
- ducting and pipe supports
SA 387 grade 9 class 2 Steel Plate Packing & Shipping
Each ask for is packaged by the customer' s checks including availability for toll, for instance, wooden case, bed or as appeared by customer's need All transportation documentation is suited sa 387 survey 9 class 2 Steel Plate improvement from plant to customer.
Each undertaking begins with a visit of our proficient approaches distribute who contemplates the volume/weight of the having a place and brief the client about pulverizing required and moreover intriguing documentation traditions while moving from India.
SA 387 grade 9 class 2 Steel Plate Application Industries
Saisteel & Engineering Co.& Alloysoffer a broad range of sa 387 grade 9 class 2 Steel Plate through a worldwide network of stock-keeping branches.these sa 387 grade 9 class 2 Steel Plate is use in various industries like:
- Mistreat things Industry
- Plane business
- Nuclear Power Plant Industry
- Creation Industry
- Oil & Gas Industry
- Refineries Industry
- Petrochemical Industry
- Paper Industry
Sai Steel & Engineering Co. is largest suppliers of A 514 steel plate. we are supplying A 514 steel plate in Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.we assured our client that we are standing behind our product which we have supplied as well as we issued a quality certificate along with our product which we manufacture supplies and exports
